  • I2S (Inter-IC Sound)


    I2S is Inter-IC Sound.

    I2S is a serial bus used to transport digital audio.

    High-end CD and DVD players feature I2S outputs. I2S inputs are found on some PC sound cards.

    I2S Pinouts

    Pin Purpose
    1 Word Clock (WCLK)
    2 Bit Clock (BCLK)
    3 DATA
    4 Master Clock (MCLK)
    5 DEM

    The pins on the male I2S jack are numbered clockwise, with the missing pin as zero.

    The pins on the female I2S plug are numbered counter-clockwise, with the missing pin as zero.
