      110 Block

      A 110 block is a punch-down block used to connect wiring for telephone systems, data network wiring, and other low-voltage wiring applications. It improves on the 66 block by supporting higher frequencies and using space more efficiently. A punch-down tool is used to force solid wire into metal slots on the 110 block. Present residences

    • How Video Conferencing Works

      How Video Conferencing Works

      Video conferencing has become popular over the last decade. Video conferencing is when two or more parties communicate in real time in separate locations with both video and audio signals. Technology Used in Video Conferencing Video conferencing works by using a few different technologies. Some of these technologies are hardware, others technologies involved in the

    • Loop


      Loops are a pair of phone numbers, usually consecutive, like 836-9998 and 836-9999. They are used by the phone company for testing. What good do loops do us? Well, they are cool in a few ways. Here is a simple use of loops. Each loop has two ends, a 'high' end, and a 'low' end.

    • DTMF (Dual-Tone Multi-Frequency)

      DTMF (Dual-Tone Multi-Frequency)

      DTMF tones, or Dual-Tone Multi-Frequency signaling, are audible tones that are used by touch-tone telephones to identify which number key was pushed by the operator. DTMF tones have been used since 1963 and are used by all standard touch-tone telephones in the United States as well as in many other countries around the world. DTMF

    • IS-54 and IS-136: TDMA

      IS-54 and IS-136: TDMA

      IS-54 and IS-136 are standards for TDMA American Digital Cellular. Mobile Frequency Range Rx: 869-894; Tx: 824-849 Multiple Access Method TDMA/FDM Duplex Method FDD Number of Channels 832 (3 users per channel) Channel Spacing 30Khz Modulation DQPSK Channel Bit Rate 48.6Kb IS-54 and IS-136: TDMA Security IS-54 and IS-136 use the CAVE (Cellular Authentication, Voice
